Metered vs Switched vs Outlet-Metered PDU: How to Choose
Every PDU RFQ we answer starts in the same place: which grade of intelligence does this rack actually need? Buy too little and you fly blind; buy too much and you pay for relays nobody throws. This guide separates the three tiers by the problem each one solves, then settles it with a decision table, five filter questions and factory-direct price bands.
Vendor datasheets make the three tiers sound like points on one quality scale, as if an outlet-metered PDU were simply a "better" metered one. They are not. Metering, switching and outlet-level metering are three different capabilities that answer three different questions: how much is this rack drawing, can I recover a hung device without a site visit, and which device consumed this energy. Your answer to those questions — not a budget line — is what should pick the tier.
If you already know your input plug and phase requirements, our selection guides cover plug charts and single- vs three-phase sizing. This article picks up after that: the intelligence tier.
The three tiers, one paragraph each
A metered PDU measures at the input: per-phase voltage, current, kW, kWh, power factor and THD at ±1% accuracy, streamed over SNMP or REST into your DCIM. It tells you what the rack draws and how balanced your phases are — it touches nothing. This is the tier for capacity planning and PUE work; see our metered rack PDU for the full measurement set.
A switched PDU puts a relay behind every outlet. You can power-cycle a hung device remotely, sequence groups on with a programmable 0-999 second delay, and enforce an on/off policy per socket. The relays are the point: rated for 100,000 mechanical cycles because recovery-by-relay is a routine operation, not an emergency hack. It is the tier for unmanned sites; the switched rack PDU page shows the sequencing logic in detail.
An outlet-metered PDU measures at every socket — current at ±1% and energy at ±2% per outlet, with a 15-minute kWh freeze value that billing systems can read. It answers the attribution question: which tenant, which miner, which cabinet row consumed what, and when. That is the tier for colocation invoicing; the outlet-metered PDU page covers the billing data model.
The tiers overlap at the top: a switched unit on our line includes input metering, and a switched + outlet-metered combo carries both relay banks and per-socket billing data. What never overlaps is the upgrade path — there is none (see the FAQ below).
The decision table: who should buy which
Match your situation to a tier before you match it to a price. Each row carries the number that usually decides it.
| Your situation | Buy this tier | Why — the number that decides | Watch out for |
|---|---|---|---|
| Enterprise rack, capacity planning and PUE | Metered | ±1% input metering feeds DCIM; global average PUE has sat at 1.56 for five years because sub-rack loads stay invisible | No per-device attribution — fine for planning, not for charging |
| Colocation billing tenants per outlet group | Outlet-Metered | Per-outlet ±1% current / ±2% kWh with 15-min freeze values invoice without disputes | Insist the input metering is billing-grade too, or the rack total and outlet sums will drift apart |
| Edge or micro-DC site, unmanned | Switched | A truck roll runs $600-1,200; one avoided reboot visit pays the tier premium | If you also trend load, order switched + metered input |
| Mining or HPC racks, per-rig P&L | Outlet-Metered (or Switched + OM) | Electricity is 75-85% of mining opex and break-even sits near $0.07-0.08/kWh — per-outlet kWh is how you find the coasting rigs | High ambient temperature; check the unit's operating range |
| Broadcast studio or OB-truck racks | Switched | Sequenced startup (0-999s delays) prevents the inrush pile-up that trips upstream breakers | Leakage-current monitoring is a separate feature — ask for it |
| Lab or GxP-regulated environment | Outlet-Metered | Exportable interval logs are audit evidence; input-only totals do not survive an audit | Check log retention depth before you commit |
| Spare or budget rack, no telemetry need | Basic | Factory-direct FOB around $60-120 — spend the difference where it matters | No remote recovery, ever. A hung device means a person and a screwdriver |
Five questions that settle it
Run these in order. The first "yes" usually names your tier.
- Does anyone invoice against this rack's energy — tenants, cost centers, per-rig P&L?Outlet-Metered
- Can a person reach this rack within an hour when a device hangs?If no: Switched
- Will this rack's load data feed capacity planning or PUE reporting?Metered
- Do devices here need ordered startup to avoid inrush trips?Switched
- Is this rack a spare, a test bench or a short-lived deployment?Basic is honest
What the tiers cost, factory-direct
Buying direct from the manufacturer, typical FOB reference bands run: basic $60-120, metered $120-260, switched $200-450, outlet-metered $260-500, and switched + outlet-metered $400-700. Three variables move you inside a band: input amperage (16A to 63A, with three-phase WYE at the top of the range — a 63A three-phase unit delivers up to 36kW), outlet count (8 to 48 per unit), and whether you need locking sockets. If a quote lands far above those bands for a standard configuration, you are paying for a logo, not for copper. Our OEM/ODM program prices custom outlet mixes and branding against the same bands.
Two mistakes we see in RFQs every week
The first is overbuying switching: a team specs switched units "for control" on racks nobody will ever remote-reboot — staffed enterprise rows where the walk to the cabinet takes ninety seconds. Those racks needed clean ±1% visibility, and the relay premium bought nothing. The second is underbuying metering for colocation: an operator deploys input-only metered PDUs, then discovers mid-contract that two tenants share a rack and the input number cannot be split. Retrofitting per-outlet metering means a forklift of every PDU in the row. The FAQ below covers the borderline case.
One more footnote for North America bound orders: whichever tier you choose, verify the safety certificate is UL 62368-1 — the old UL 60950-1 was withdrawn on 2020-12-20 and a "60950-certified" new unit is a red flag. We explain the timeline in UL 62368-1 Explained, and the metering claims in What ±1% Billing-Grade Metering Actually Means.
Frequently asked questions
No. Per-outlet switching needs a relay behind every socket, a switching PCBA and a control processor — hardware that has to be designed in and tested at the factory. Decide the tier at purchase; a metered unit cannot be field-upgraded to switched.
On AmpRack switched PDUs, yes at the input: phase-level V, A, kW, kWh and power factor stream over SNMP alongside switching. What a plain switched unit does not give you is per-outlet kWh — that requires the outlet-metered grade, available on its own or combined as switched + outlet-metered.
If each rack houses exactly one tenant and the contract references the feed, ±1% input metering is defensible. The moment two tenants share a rack or a tenant adds equipment mid-month, input-only numbers become estimates. Shared racks need per-outlet kWh with interval freeze values to invoice without arguments.
Sources: Cloudatler, Edge AI / micro data center TCO handbook (truck roll cost basis, cloudatler.com) · Simple Mining, 2026 mining profitability analysis (electricity share of opex and break-even kWh price, simplemining.io) · Uptime Institute, Global Data Center Survey (PUE plateau, uptimeinstitute.com) · AmpRack factory-direct FOB reference bands, September 2026. Price bands are orientation values; request a formal quote for your configuration.
