Fit the rack, not the catalogue
Every line below is the same metering and switching platform, re-cut for one deployment context: the current per feed, the outlet rank, the metering depth and whether the cabinet is attended.
- Metering accuracy
- +/-1% Current, voltage and power, per reporting line
- Input range, meter
- 90V ~ 350V Scale 1V, +/-1% + 1 digit
- Ambient sensing
- -30°C ~ 100°C 1°C resolution; humidity 1% ~ 99%
- Event storage
- 20,000 Entries, held by the built-in RTC through power loss
Row to reporting line
What changes between industries
The chassis, the conductor and the firmware do not change. What changes is the split of current, the outlet mix and the depth of metering the buyer is willing to pay for.
| Deployment context | Feed | Metering depth | Data path |
|---|---|---|---|
| Data hall | 3-phase 32A | Total per feed | SNMP v1/v2c |
| Server room | 1-phase 16A | Total per feed | SNMP v1/v2c |
| Colocation | 3-phase 16A / 32A | Per outlet | SNMP + Modbus TCP |
| Laboratory and test rack | 1-phase 10A | Per outlet | Modbus RTU 9600 8N1 |
| Edge cabinet | 1-phase 16A | Total per feed | SNMP trap to SMTP |
| Telecom cabinet | 1-phase 16A | Total per feed | RS485 |
Rack
Busbar
Breaker
Outlets
Metering
SNMP
Ambient
Event log
Aisle walk
Read the rack before writing the line
An aisle walk takes six readings: inlet current per feed, phase balance, outlet count by type, ambient at the top of the cabinet, whether the cabinet is locked, and whether anyone is on site to press a button. Those six answers fix the metering depth and the switching need.
- Inlet current
- 10A / 16A / 32A
- Supply voltage
- 110V ~ 250V AC
- Frequency
- 50Hz ~ 60Hz
- Outlet rank
- C39x4 + C13x36
- Conductors
- VDE VDE 2.5mm2 / 6mm2#
- Wide-input range
- 180 ~ 265V
Cabinet
Current
Drawings
Test
From reading to release
Four steps, each with its own evidence
-
Deployment read
Inlet current, phase balance, outlet mix and ambient at the top of the cabinet go onto one sheet. Buyers send the sheet or the cabinet photograph.
Evidence: measured current per feed -
Firmware match
Total per feed or per outlet metering, SNMP or Modbus, trap or SMTP alerting. Protocol choice follows what the site already polls.
Evidence: protocol and MIB list -
Build and 100% test
Busbar connection, breaker rating, conductor cross-section then a full electrical test on every unit before it is packed. No batch sampling.
Evidence: test record per serial -
Release pack
Per-line specification sheet, outline drawings by mounting orientation, meter register map and the certificate titles with the legal holder named.
Evidence: document list, current revision
Deployment contexts we build for
-
Data hall
Row-level feeds, dense outlet ranks, cabinet-level aggregation on one bus.
- Feed 3-phase 32A
- Metering total per feed
- Typical unit 20 x 20A (SA-20)
-
Colocation
Billing-grade energy per tenant circuit, with the register readable over the wire.
- Feed 3-phase 16A / 32A
- Metering per outlet
- Energy grade 1 grade, Scale 0.1 kWh
-
Laboratory and test rack
Per-outlet data for bench campaigns, low current, frequent re-plugging.
- Feed 1-phase 10A
- Metering per outlet
- Log 20,000 entries, RTC held
Send the rack
Name the context, get the line
Outlet combination, current per feed, metering depth and whether remote switching is needed. Four lines are enough to size the feed; the configured quotation and the per-line specification sheet come back in English.
Inquiries are answered within 12 business hours. Printed specification sheets and outline drawings ship with the unit.
