Quoting, documents and how a build runs
Most enquiries resolve on four lines of electrical data and three documents. This page states what those are, and what happens at each step after them.
- Reply window
- within 12 hours
- Order basis
- drawing or sample
- Quotation
- per line, English
- Drawings
- by unit and orientation
- Certificates
- titles and holder
The four lines, and what each one decides
Four fields carry a quotation. Everything else follows from them, including the enclosure family, the breaker rating and the metering lines.
Reply within 12 hours on working days- Outlet combination
- C13, C19, C19 counts
- Current per feed
- 10A to 32A
- Metering depth
- total per feed, or per outlet
- Remote switching
- per outlet, per group, or none
- Mounting orientation
- 1U, 2U, 3U, 9U, zero-U
- Input window
- 110V to 250V AC, 180 to 265V option
- Frequency
- 50Hz to 60Hz
- Documentation set
- specification sheet, drawings, certificate titles
A drawing beats a description
If a drawing or a sample already exists, the outlet set and the current per feed are read from it. That removes the round trip on outlet counts and keeps the first reply close to the final quotation.
Metering class on every quotation: ±1% · energy grade 1What buyers ask before a first order
Six questions come back most often. Each answer names the document or the measurement behind it.
Four lines: outlet combination, current per feed, metering depth, and whether remote switching is required. Add the mounting orientation, and the reply can be a configured quotation rather than a range.
A specification sheet written per line, outline drawings by unit and mounting orientation, and the certificate titles with the holding entity named. A configured quotation states the metering depth and the switching scope explicitly.
No. The UL evidence is a component certificate for audio, video and information technology equipment, certified to UL 62368-1. It is held by Ningbo DCDU Power Distribution Equipment Co., Ltd., the legal entity.
Current, voltage and power are compared against a reference instrument on each reporting line, at ±1% plus one digit. Total energy is checked on a 1 grade scale of 0.1 kWh, and the result is recorded per line.
Yes, as a new drawing revision. The revision is confirmed in writing, the cut and fold program follows it, and the first article is rebuilt before the series continues.
The outlet row is protected, the unit is packed with the document set inside, and the test record and the per-line specification sheet travel with it. Dispatch dates are quoted per order, not published as a site figure.
Documents held on file
What a configured quotation contains
A quotation is only useful if it can be checked line by line. Each document below answers a question that would otherwise come back as an email.
- Specification sheet
- per line, current revision
- Outline drawings
- by unit and orientation
- Test record
- per reporting line
- Certificate titles
- titles and holder named
Six steps from enquiry to dispatch
The sequence is the same for a first article and a repeat order. Two steps depend on you: confirming the drawing revision and confirming the document set.
Enquiry received
The four lines arrive through the form or against a drawing. A working-day reply follows within 12 hours.
You send: outlet combination, current, metering depth, switchingLoad check
Current per feed is checked against the inlet, the breaker and the enclosure family. Where a request exceeds the inlet, the reply says which field to change.
We check: inlet, breaker, enclosureConfigured quotation
The quotation is written in English and priced per line, with metering depth and switching scope stated. No lead time or minimum quantity figure is published on this site.
You confirm: configuration and documentsOutline drawing
Mounting orientation, cable entry and outlet order are drawn by unit. The revision is confirmed in writing before any steel is cut.
You confirm: drawing revisionBuild and test
The unit is built at the stations, wired to VDE 2.5mm² or 6mm², and powered for the full electrical test list. Metering is compared against a reference.
We record: test record per linePack and dispatch
The outlet row is protected and the document set goes inside the package. Test record, specification sheet and certificate titles travel with the unit.
You receive: unit, record, documents
Send the four lines. The reply names the documents.
Outlet combination, current per feed, metering depth and switching scope. The answer comes back in English with a per-line specification sheet.
- Reply window
- within 12 hours
- Quotation
- English, per line
- Documents
- sheet, drawings, titles
