A vertical zero-U rack PDU mounted on the side of a rack, photographed from a raised three-quarter angle with the outlet row running the full chassis height and the unit held in the left of the frame, the right side in unlit dark

IDCPDU · Vertical

Vertical rack PDU: the outlet row leaves the 1U bays alone

A zero-U chassis mounts on the side of the rack, 44mm across, up to 1800mm long, so the front bays stay free for equipment. Internals run on VDE 2.5mm2 or 6mm2 copper busbar and.

Request a quote Open the specifications

Mounting: side bracket, zero-U
Section width: 44mm
Lengths: to 1800mm
Internals: VDE 2.5mm2 / 6mm2
Conductors: , copper busbar
Feed: 10A ~ 32A · 50Hz ~ 60Hz

A vertical zero-U rack PDU installed on the side rail of a rack, seen from a low three-quarter angle inside a dark equipment aisle with the rack rails and a receding row of closed cabinets out of focus behind it

Vertical zero-U form · 1024x1024 · side-mount chassis with the full-height outlet row

Fit

Where the chassis goes, and what it frees

A rack that runs out of front space runs out of power outlets at the same time. The vertical chassis is bolted to the side rail, so the outlets move to the one face of the rack that was already empty and the 1U bays stay free for equipment. Outlet order follows the drawing: the row runs top to bottom in the sequence the rack was cabled for, so a device can be traced to its outlet without pulling the unit.

Mounting: side bracket, zero-U
Section width: 44mm
Standard lengths: to 1800mm
Internal conductors: VDE VDE 2.5mm2 / 6mm2

Vertical parameters

Chassis and electrical envelope

Lengths, section and conductor sizes are the three values that decide whether the chassis fits the rack, so they open the parameter table.

Table 1 · vertical chassis envelope
Item	Value	Basis
Mounting	side rail, zero-U	Bracket set supplied with the unit
Section width	44mm	Chassis across the rack depth
Standard lengths	to 1800mm	Cut per rack height at order
Internal conductors	VDE 2.5mm2 / 6mm2	Rated to the feed current
Input / output current	10A ~ 32A / 10A ~ 16A	Feed breaker and outlet rating
Working voltage	110V AC ~ 250V AC	Single phase or three phase
Frequency	50Hz ~ 60Hz	Metering and switching logic
Outlet types	IEC C13 10A / IEC C19 16A	Mixed on one row from the drawing
Metering accuracy	1% current, voltage, power	Where the metered option is fitted

Vertical values

Eight figures on the zero-U chassis

These are the values a rack drawing has to answer before the chassis can be cut.

Mounting side rail Zero-U bracket set, front bays left free.

Section 44mm Chassis width across the rack depth.

Length to 1800mm Cut to the rack height at order.

Current 10A ~ 32A Feed breaker above the configured load.

Conductors VDE 2.5mm2 / 6mm2 , copper busbar joints.

Metering 1% Current, voltage and power on the metered build.

Reporting SNMP / Modbus Ethernet and RS485 on one board.

Compliance UL 62368-1 component CE and RoHS as applicable.

Mounting

Four checks before the chassis is cut

Rack height

Usable side-rail length sets the chassis length, up to 1800mm.

Rail drilling

Bracket hole pattern is taken from the rack photo or the rail drawing you send.

Cable entry

Inlet and outlet entry faces are fixed before the sheet metal is cut.

Outlet order

Left to right, top to bottom, in the sequence the rack is cabled for.

Side rail

The face of the rack that was already empty

A vertical chassis trades the front bays for the two side rails, and the trade is the point of the form: the outlet row ends up where nothing else was competing for space.

A deep charcoal gradient field with one thin warm accent edge along the top, used as the backing of the closing request section

Request a quote

Send the rack height, get the chassis length

Outlet combination, current per feed, rack height and the mounting face. The configured quotation returns with the outline drawing and the per-line specification sheet in English.

Request a quote Datasheets and downloads

Reply promisewithin 12 hours, weekdays
With the quoteoutline drawing, outlet order
On requestcertificate names and holders
