An equipment cabinet in a server room, the rack PDU inside it lit by one lamp while the cabinet row behind it stays dark
Current per feed
10A ~ 32A
Working voltage
110V ~ 250V AC
Frequency
50Hz ~ 60Hz
Local display
Industrial OLED
Reporting
SNMP / Modbus

Home Industries Server room

Server room

A reading anyone on site can take

An equipment room is usually unattended until something trips. The unit carries an industrial OLED that shows IP address, current, voltage, power, energy and the main switch state at the cabinet, and the same register set leaves over Ethernet for whoever is not standing in front of it.

Request a quote
A rack PDU installed in a small server room aisle, seen from a low angle with the outlet rank lit and the floor tiles running away behind it
Cabinet reading, taken at the rack. industries-server-room-b2

Local readout

What the OLED shows at the cabinet

A server room rarely has a monitoring screen on the wall. The panel on the unit answers the question a technician actually arrives with, and it does so without a login: the address the unit answers on, the load it is carrying, and whether the main switch is closed.

IP address
10/100M port
Current
0.1A scale
Voltage
1V scale
Active power
+/-1%
Energy
0.1 kWh scale
Main switch
Open / closed
  • Reading a technician takes first current per feed
  • Reading that explains a trip main switch state
  • Reading a landlord asks for energy per line
Feed current runs 10A to 32A on the input and 10A to 16A at the outlets, so a single-phase room and a small three-phase room are served by the same chassis family.

Parameters the room is checked against

Server room line sheet

Every row below is a value a small equipment room is actually planned around: what one feed can carry, what the meter window tolerates, and what the outlet rank has to hand out.

Rack PDU parameters for server room distribution
Parameter Value Note
Working voltage110V ~ 250V ACSingle-phase feeds
Working frequency50Hz ~ 60HzBoth nominal supplies
Input current10A ~ 32APer feed, matched to the breaker
Output current10A ~ 16APer outlet group
Outlet typesIEC C13 / C1910A and 16A bodies
Metering accuracy+/-1%Current, voltage and power
Voltage scale, meter1VRange 90V ~ 350V
Current scale, meter0.1A+/-1% + 1 digit
Energy register1 grade, 0.1 kWhBilling-grade total energy
Basic protectionBreaker, 1P to 3PRating set per feed
Mounting1U horizontal / verticalZero-U keeps rack units free

A server room has less headroom than a data hall row, so the two decisions that matter are current per feed and where the unit is mounted. A vertical unit takes no rack units and puts the outlet rank where the cables already run.

Surge protection sits on the wide-input path at 180 ~ 265V. On a site where the supply sags before a generator takes over, that path is the difference between a logged event and a dropped cabinet.
  • Cabinet
  • Breaker
  • Outlets
  • Current
  • Metering
  • Network

Register grid

Readings a room this size needs

Each cell is one register group on the reporting line. A small room does not need per-outlet billing on every cabinet, but it does need to know which feed is close to its breaker.

  • Input current 0.1A Per feed, 10A to 32A range. +/-1% + 1 digit on the reported figure.
  • Voltage 1V Working window 110V ~ 250V AC, meter window 90V ~ 350V.
  • Active power +/-1% Reported alongside current and voltage on the same line.
  • Energy 0.1 kWh 1 grade register, so a landlord reading and a tenant reading come from one source.
  • Cabinet ambient 1°C Sensor range -30°C ~ 100°C, humidity 1% ~ 99%.
  • Data path 10/100M Ethernet plus one RS485 port. SNMP and Modbus, embedded web server, SMTP alerts.
Frequency is reported across the 50Hz ~ 60Hz band, so the same unit ships to a 60Hz site without a firmware variant.
Macro view of the IEC outlet rank on a rack PDU, one cable seated and the brushed steel visible between the outlet bodies
Outlet rank at the cabinet. industries-server-room-b5

What travels with the unit

Certificates, named and held

The certificate list states the title, the standard and the legal holder. Certificate numbers are not printed here; the scans travel with the current revision of the line sheet, on request.

  • Certified to UL 62368-1 (component)Ningbo DCDU Power Distribution Equipment Co., Ltd.
  • CE-LVD and CE-EMCAssessed as applicable to the line
  • RoHS (TUV)Restricted substances, assessed as applicable
  • ISO 9001 quality managementHolder named on the certificate
  • Electrical testing100% electrical testing before packing
  • Recycled content declarationOver 95% recycled content, declared by the holder

Related Data hall distribution Quality and testing

A rack PDU face lit by one raking light across brushed steel, the outlet rank running out of focus towards the back of the frame

Send the rack

Cabinet, feed current, outlet mix

Tell us how many rack units you can give up, what the feed breaker is rated at, and whether the room has a network point. The reply is a configured quotation with a per-line specification sheet, in English.

Request a quote Selection guides
Inquiries are answered within 12 business hours. Mounting orientation and outline drawings come back with the quotation.
Macro view of the readout panel on a rack PDU, the small OLED lit with abstract metering characters and no legible words
Panel readout, no legible words on the glass. industries-server-room-b6
