A switched rack PDU with its breaker bank in the left of the frame, one raking light skimming the brushed steel face and the outlet row stepping back into darkness on the right

IDCPDU · Switched

Switched rack PDU: a remote hand on every outlet group

Breaker per group or per outlet with remote power cycling over SNMP, Modbus or the onboard web server. SMTP traps report the state change, and the metering board keeps 1% accuracy on the same feed.

Request a quote Open the specifications

Switching: per outlet or per group
Protocols: SNMP, Modbus, RS485
Interfaces: 10/100M Ethernet x1
Alerts: SMTP, threshold configurable
De-energised restart: Off, On, or last state
Metering accuracy: 1% on the same feed

Switching parameters

What is switched, and what watches it

The relay schedule is part of the order, not a setting discovered on site, so each outlet group is assigned a mode before the unit is built.

Table 1 · switching and control envelope
Item	Value	Basis
Switched points	per outlet or per group	Relay schedule from the order
Remote control	SNMP set, Modbus write, web page	Embedded web server on board
Interfaces	10/100M Ethernet x1, RS485 x1	One control board
De-energised restart	Off / On / last state	Configurable per group
Current per feed	10A ~ 32A	Breaker above configured load
Metering accuracy	1% current, voltage, power	Per reporting line
Alerts	SMTP, threshold configurable	Sent by the unit, no agent
Outlet types	IEC C13 10A / IEC C19 16A	Count and order from the drawing

Switching modes

Five states a group can hold

Each group is assigned one of these modes at order, so a reboot command has a defined result rather than a guess.

Mode 01Offno output on the group

Mode 02Onoutput held live

Mode 03Last statereturns live after a power cut

Mode 04Timed cyclecommanded reboot window

Mode 05Groupedseveral outlets, one command

Interfaces2Ethernet and RS485 in parallel

A switched rack PDU installed in a dark equipment aisle, seen from a low three-quarter angle with rack rails and a receding row of closed cabinets out of focus behind the unit, the chassis held right of frame

Protection

One protective device per group, not one per chassis

The inlet breaker alone cannot separate a single failed supply from the rest of the rack, so the switched type carries a protective device per outlet group. A trip takes one group dark and the alarm names it; the remaining groups keep their state and their metering.

Protective devicesone per outlet group
Group alarmSMTP, named in the message
Unaffected groupsstate and metering held
Feed rating10A ~ 32A

Alerts and thresholds Per-outlet monitoring

Control surface

Eight values on the switched type

Switched points per outlet or group Relay schedule fixed at order.

Feed current 10A ~ 32A Breaker above the configured load.

Metering 1% Held on the same feed as the switchgear.

Interfaces Ethernet, RS485 SNMP and Modbus on one control board.

Alerts SMTP traps Thresholds configurable after delivery.

Event log 20,000 Records with the real-time clock held.

Local display OLED Current, voltage, power, energy, switch state.

Compliance UL 62368-1 component CE and RoHS as applicable.

A deep charcoal gradient field with one thin warm accent edge along the top, used as the backing of the closing request section

Request a quote

Name the groups, get the relay schedule

Outlet combination, current per feed, which groups are switched and which protocol the control system speaks. The configured quotation and the per-line specification sheet come back in English.

Request a quote Datasheets and downloads

Reply promisewithin 12 hours, weekdays
With the quoterelay schedule, register map
On requestcertificate names and holders
