A horizontal 1U rack PDU photographed from a raised three-quarter angle with the outlet row running across the front face and the OLED panel at its left end, the unit held in the right of the frame and the left side in unlit dark

IDCPDU · Horizontal

Horizontal rack PDU: one rack unit, display at eye height

The 1U chassis carries the outlet row across the front with the OLED panel inside the same face, so current, voltage, power, energy and the main switch state are readable without opening the rack.

Request a quote Open the specifications

Form: 1U, 44.45mm
Outlet row: front facing, mixed
Display: OLED, 6 values
Feed: 10A ~ 32A · 50Hz ~ 60Hz
Voltage: 110V AC ~ 250V AC
Reporting: SNMP / Modbus · Ethernet

1U parameters

One rack unit, and what fits in it

A 1U face gives 44.45mm of height, so the outlet count, the display and the breaker bank compete for the same strip. The order decides which of the three takes the space.

Table 1 · horizontal chassis envelope
Item	Value	Basis
Form factor	1U, 44.45mm	Front-mount in the rack
Working voltage	110V AC ~ 250V AC	Single phase or three phase
Input / output current	10A ~ 32A / 10A ~ 16A	Feed breaker and outlet rating
Frequency	50Hz ~ 60Hz	Metering and switching logic
Display	OLED	IP, current, voltage, power, energy, switch state
Outlet types	IEC C13 10A / IEC C19 16A	Mixed across the front face
Internal conductors	VDE VDE 2.5mm2 / 6mm2	Copper busbar joints
Reporting	10/100M Ethernet, RS485	SNMP, Modbus, embedded web server
Metering accuracy	1% current, voltage, power	On the metered build
Compliance	IEC / NEMA; CE, RoHS	UL 62368-1 component certificate

A horizontal 1U rack PDU installed in a rack, seen from a low three-quarter angle inside a dark equipment aisle with the rack rails and a receding row of closed cabinets out of focus behind it, the front face held right of frame

Horizontal 1U form · 1024x1024 · front outlet row with the panel at the left end

Panel

Six values on the front face

The panel is part of the chassis rather than a separate meter, so the reading is at eye height on the unit that carries the outlets. Current and voltage are reported with the same 1% accuracy as the network registers, and the energy total accumulates on the billing-grade register at 0.1 kWh scale.

Panel values: IP, current, voltage, power, energy, switch state
Accuracy: 1% current, voltage, power
Energy scale: 0.1 kWh, 1 grade
Repeated on: web page and SNMP object

1U values

Four figures that fill a 1U face

Height is the constraint in a 1U chassis, so these four values decide what the front face can carry.

Form factor 1U, 44.45mm Front-mount across one rack unit.

Outlet row front facing C13 and C19 mixed by drawing.

Display OLED Six values plus main switch state.

Compliance UL 62368-1 component CE and RoHS as applicable to the build.

Layout

Four decisions on a 44.45mm strip

Outlet mix

C13 and C19 counts, and the order they sit in across the front face.

Panel position

Left end, right end or centre, so the display stays readable after cabling.

Breaker bank

One device per group on the same face, or grouped behind a single inlet breaker.

Cable entry

Rear or side entry, fixed before the sheet metal is cut.

A deep charcoal gradient field with one thin warm accent edge along the top, used as the backing of the closing request section

Request a quote

Send the outlet list, get the front-face layout

Outlet combination, current per feed, display requirement and the reporting protocol in use. The configured quotation returns with the front-face layout and the per-line specification sheet in English.

Request a quote Datasheets and downloads

Reply promisewithin 12 hours, weekdays
With the quotefront-face layout, outlet order
On requestcertificate names and holders
